Wilhelmshaven / Mariensiel Airfield

Wilhelmshaven / Mariensiel AirfieldFlugplatz Wilhelmshaven-Mariensiel direkt am Jadebusen gelegen.

10 Minuten entfernt vom einzigen Tiefwasserhafen Deutschlands.

Mit dem Kfz erreichen Sie uns schnell über die BAB A29, Anfahrt Sande, dann der Ausschilderung folgen.





Unser Service für Sie:

- Fahrradverleih: 1 Fahrrad bis 6 Stunden, 2€; pro Tag, 4€
- Unterkunft: Privatunterkunft- oder Hotellisten senden wir Ihnen gern per Fax zu
- Taxi: Der Wagen steht innerhalb von 10 Minuten vor der Tür. Gern bestellen wir den Wagen für Sie.
- Bahnhof: Der Bahnhof Sande ist nur ca. 5 Autominuten von unserem Flugplatz entfernt.

Wilhelmshaven / Mariensiel AirfieldICAO Code EDWI
Name WILHELMSHAVEN - Mariensiel
Land Deutschland
Bundesland Niedersachsen
Letzte Änderung 30. Juni 2005

Kategorie Verkehrslandeplatz / Public Airfield
Betreiber / Operator Flugplatzgesellschaft Wilhelmshaven-Friesland mbH

Lage / Location 2.2 NM SW Wilhelmshaven
Nachtflug / NVFR NVFR
LFZ / ACFT Bis / up to 3000 kg , 14000 kg PPR, HEL 20000 kg
Helicopter Ja / Yes
Segelflugzeuge / GLD Ja / Yes
UL Ja / Yes
GLD (P,selbststartend/self-launching)
Summer 0600-SS+30/1900
Winter 0700-SS+30
O/T PPR
Einschränkungen siehe AD 1-6/ restrictions see AD 1-6
Luftaufsicht / OPS +49 (0)4421 / 201085, Fax 203514
PPR +49 (0)4421 / 201085, Fax 203514
AIS AIS-Centre +49 (0)69 / 78072500
ACC EDDW +49 (0)421 / 553230
MET (0190) 077221
Gafor 1

Zoll / Customs 2 HR O/R nur für Reisende ohne Handelsware - Ein-und Ausflugabfertigung durch die Luftaufsicht/for passengers without merchandise only - entry and exit clearence by Luftaufsicht
Zoll / Customs Fon +49 (0)4421 / 202333
Fuel 100 LL, Jet A1
Oil 80, D80, 100, D100, 20W50
Hangar Ja / Yes
Höhe / Elevation 16 ft / 5 m
FIS Bremen Information 125.100
VDF / QDM 129.250
Rufzeichen / Call sign Wilhelmshaven Info
Frequenz Tower 129.250 EN/GE
NAV Aids 288°/31 NM from WSR 112.90
Koordinaten 53 30, 29 N / 08 03, 20 E
Platzrunde / Traffic circuit E 600
Landebahnen / RWY 2
RWY 1459 x 30 m, ASPHALT
RWY 02 TKOF 1207 m; LDG 1233 m
RWY 20 TKOF 981 m; LDG 1207 m
MTOW 3000 kg, PPR 14000 kg, HEL 20000 kg
RWY II 615 x 15 m, ASPHALT
RWY 16 TKOF 592 m; LDG 615 m
RWY 34 TKOF 615 m; LDG 592 m
MTOW RWY II 3000 kg, Heli 20000 kg
Bemerkungen / Remarks Jever CTR (2500 MSL) ARR/DEP nur von/nach S oder N/ARR/DEP only to or from S or N - Wohngebiete meiden!
Restaurant Ja

Adresse
Flugplatz Mariensiel
ZIP / City D-26452 Sande

Fon +49 (0)4421 / 202333,
Fax 203514

URL www.edwi.info
eMail info at edwi info


Images and information placed above are from www.edwi.info
http://www.airports.de/airport.php?ICAO=EDWI
We thank them for the data!


General Info
Country Germany
ICAO ID EDWI
Time UTC+1(+2DT)
Latitude 53.504833
53° 30' 17.40" N
Longitude 8.053333
008° 03' 12.00" E
Elevation 16 feet
5 meters
Type Civil
Magnetic Variation 000° E (01/05)
Beacon Yes
Operating Agency CIVIL GOVERNMENT, (LANDING FEES AND DIPLOMATIC CLEARANCE MAY BE REQUIRED)
Operating Hours SEE REMARKS FOR OPERATING HOURS OR COMMUNICATIONS FOR POSSIBLE HOURS
Daylight Savings Time Last Sunday in March to last Sunday in October


Communications
JEVER TWR 118.725
122.1
INFO 129.25
BREMEN INFO 125.1


Runways
ID
Dimensions Surface PCN ILS
02/20 4787 x 98 feet
1459 x 30 meters
ASPHALT - NO
16/34 2018 x 49 feet
615 x 15 meters
ASPHALT - NO


Supplies/Equipment
Fuel Jet A1, without icing nhibitor.

100/130 MIL Spec, low lead, aviation gasoline (BLUE)


Remarks
CSTMS/AG/IMG Avbl O/R fone C04421-202333.
FUEL (NC-100LL, A1)
MISC Fone C04421-201085.
NS ABTMT Before 0600Z++, btn 1200-1400Z++, aft SS Mon-Fri. Before 0800Z++ and aft 1200Z++Sat, Sun, hol.
OPR HOURS Opr 0700Z-SS+30, (0600Z-SS+30/1900 DT), OT PPR.

Runway 02/20

4787 x 98 feet
1459 x 30 meters

Runway 02
Surface ASPHALT
True Heading 020.0
Latitude 53.497581
53° 29' 51.29" N
Longitude 8.048906
008° 02' 56.06" E
Landing Distance 4046 feet
1233 meters
Takeoff Distance 4787 feet
1459 meters
Displaced Threshold Length 741 feet
226 meters
Lighting System HIRL

Runway 20
Surface ASPHALT
True Heading 200.0
Latitude 53.509900
53° 30' 35.64" N
Longitude 8.056428
008° 03' 23.14" E
Landing Distance 3960 feet
1207 meters
Takeoff Distance 4787 feet
1459 meters
Displaced Threshold Length 827 feet
252 meters
Lighting System HIRL

Runway 16/34

2018 x 49 feet
615 x 15 meters

Runway 16
Surface ASPHALT
True Heading 161.0
Latitude 53.507461
53° 30' 26.86" N
Longitude 8.051250
008° 03' 04.50" E
Landing Distance 2018 feet
615 meters
Takeoff Distance 2018 feet
615 meters
Lighting System LIRL

Runway 34
Surface ASPHALT
True Heading 341.0
Latitude 53.502258
53° 30' 08.13" N
Longitude 8.054186
008° 03' 15.07" E
Landing Distance 1920 feet
585 meters
Takeoff Distance 2018 feet
615 meters
Displaced Threshold Length 98 feet
30 meters
Lighting System LIRL




Thanks to: www.worldaerodata.com

The content above was published at Airports-Worldwide.com in 2005.
We don't guarantee the information is fresh and accurate. The data may be wrong or outdated.
For more up-to-date information please refer to other sources.
