An artist's conception of aerobraking with the Mars Reconnaissance Orbiter

Aerobraking is a spaceflight maneuver that reduces the high point of an elliptical orbit (apoapsis) by flying the vehicle through the atmosphere at the low point of the orbit (periapsis). The resulting drag slows the spacecraft. Aerobraking is used when a spacecraft requires a low orbit after arriving at a body with an atmosphere, and it requires less fuel than does the direct use of a rocket engine.

Method

When an interplanetary vehicle arrives at its destination, it must change its velocity to remain in the vicinity of that body. When a low, near-circular orbit around a body with substantial gravity (as is required for many scientific studies) is needed, the total required velocity changes can be on the order of several kilometers per second. If done by direct propulsion, the rocket equation dictates that a large fraction of the spacecraft mass must be fuel. This in turn means the spacecraft is limited to a relatively small science payload and/or the use of a very large and expensive launcher. Provided the target body has an atmosphere, aerobraking can be used to reduce fuel requirements. The use of a relatively small burn allows the spacecraft to be captured into a very elongated elliptic orbit. Aerobraking is then used to circularize the orbit. If the atmosphere is thick enough, a single pass through it can be sufficient to slow a spacecraft as needed. However, to reduce the effect of frictional heating, and because the unpredictability turbulence effects, atmospheric composition, and temperature make it difficult to accurately predict the decrease in speed that will result from any one pass through the atmosphere, aerobraking is typically done with many orbital passes through a higher altitude, and therefore thinner, region of the atmosphere. When aerobraking is done in this way, there is sufficient time after each pass to measure the change in velocity and make any necessary corrections for the next pass. Achieving the final orbit using this method takes a long time (e.g., over six months when arriving at Mars), and may require several hundred passes through the atmosphere of the planet or moon. During the last aerobraking pass, the spacecraft must be given more kinetic energy via rocket engines in order to raise the periapsis above the atmosphere--unless, of course, the intent is to land the spacecraft.

The kinetic energy dissipated by aerobraking is converted to heat, meaning that a spacecraft using the technique needs to be capable of dissipating said heat. The spacecraft must also have sufficient surface area and structural strength to produce and survive the required drag, but the temperatures and pressures associated with aerobraking are not as severe as those of reentry or aerocapture. Simulations of the Mars Reconnaissance Orbiter aerobraking use a force limit of 0.35 N per square meter with a spacecraft cross section of about 37 m², and a maximum expected temperature as 340 °F (170 °C). The force, of roughly 0.2 N (0.04 lbf) per square meter, that was exerted on the Mars Observer, during aerobraking is comparable to the force of a 40 mph (60 km/h) wind on a human hand at sea level on Earth.

Related methods

Aerocapture is a related but more extreme method in which no initial orbit-injection burn is performed. Instead, the spacecraft plunges deeply into the atmosphere without an initial insertion burn, and emerges from this single pass in the atmosphere with an apoapsis near that of the desired orbit. Several small correction burns are then used to raise the periapsis and perform final adjustments. This method was originally planned for the Mars Odyssey orbiter, but the significant design impacts proved too costly.

Another related technique is that of aerogravity assist, in which the spacecraft flies through the upper atmosphere and utilises aerodynamic lift instead of drag at the point of closest approach. If correctly oriented, this can increase the deflection angle above that of a pure gravity assist, resulting in a larger delta-v.

Spacecraft missions

Although the theory of aerobraking is well developed, utilising the technique is difficult because a very detailed knowledge of the character of the target planet's atmosphere is needed in order to plan the maneuver correctly. Currently, the deceleration is monitored during each maneuver and plans are modified accordingly. Since no spacecraft can yet aerobrake safely on its own, this requires constant attention from both human controllers and the Deep Space Network. This is particularly true near the end of the process, when the drag passes are relatively close together (only about 2 hours apart for Mars).

Aerobraking was first used during the extended Venusian mission of the Magellan spacecraft. It was used to circularize the orbit of the spacecraft in order to increase the precision of the measurement of the gravity field. The entire gravity field was mapped from the circular orbit during a 243 day cycle of the extended mission. During the termination phase of the mission, a "windmill experiment", in which atmospheric drag was used to deorbit the Magellan spacecraft, was performed.

In 1997, the Mars Global Surveyor (MGS) orbiter was the first spacecraft to use aerobraking as the main planned technique of orbit adjustment. The MGS used the data gathered from the Magellan mission to Venus to plan its aerobraking technique. The spacecraft used its solar panels as "wings" to control its passage through the tenuous upper atmosphere of Mars and lower the apoapsis of its orbit over the course of many months. Unfortunately, a structural failure shortly after launch severely damaged one of the MGS's solar panels and necessitated a higher aerobraking altitude (and hence one third the force) than originally planned, significantly extending the time required to attain the desired orbit. More recently, aerobraking was used by the Mars Odyssey and Mars Reconnaissance Orbiter spacecraft, in both cases without incident.

Aerobraking in fiction

In Robert A. Heinlein's fictional 1948 novel Space Cadet, aerobraking is used to save fuel while slowing the spacecraft Aes Triplex for an unplanned extended mission and landing on Venus, during a transit from the Asteroid Belt to Earth.

In the movie 2010: The Year We Make Contact, the Leonov uses aerobraking in Jupiter's atmosphere to rendezvous with the Discovery.

See also

• lithobraking
• Atmospheric reentry
• aerocapture
