Dennis F Cantrell Field Airport



Dennis F Cantrell Field Airport


Location & QuickFacts

FAA Information Effective:

2005-10-27

Airport Identifier:

CWS

Longitude/Latitude:

092-25-29.8620W/35-04-50.9080N
-92.424962/35.080808 (Estimated)

Elevation:

315 ft / 96.01 m (Surveyed)

Land:

198 acres

From nearest city:

1 nautical miles SE of Conway, AR

Location:

Faulkner County, AR

Magnetic Variation:

05E (1980)

Owner & Manager

Ownership:

Publicly owned

Owner:

City Of Conway

Address:

1201 Oak Street
Conway, AR 72032

Phone number:

501-450-6110

Manager:

Bill Cope

Address:

425 6th Street
Conway, AR 72032

Phone number:

501-327-4559

Airport Operations and Facilities

Airport Use:

Open to public

Wind indicator:

Yes

Segmented Circle:

Yes

Control Tower:

No

Attendance Schedule:

ALL/ALL/DALGT
FOR SVC AFT HRS CALL 501-269-4559; FEE CHARGED.

Lighting Schedule:

DUSK-DAWN
ACTVT MIRL RY 08/26 - CTAF.

Beacon Color:

Clear-Green (lighted land airport)

Landing fee charge:

No

Sectional chart:

Memphis

Region:

ASW - Southwest

Boundary ARTCC:

ZME - Memphis

Tie-in FSS:

JBR - Jonesboro

FSS on Airport:

No

FSS Phone:

870-935-3471

FSS Toll Free:

1-800-WX-BRIEF

NOTAMs Facility:

JBR (NOTAM-d service avaliable)

Federal Agreements:

NY1

Airport Communications

CTAF:

122.800

Unicom:

122.800

Airport Services

Fuel available:

100LLA

Runway Information

Runway 08/26

Dimension:

4875 x 100 ft / 1485.9 x 30.5 m

Surface:

ASPH, Fair Condition

Weight Limit:

Single wheel: 12000 lbs.

Edge Lights:

Non-standard lighting system
NSTD MIRL; THLD LGTS NSTD.
MIRL OTS INDEFLY.



Runway 08

Runway 26

Longitude:

092-25-55.7900W

092-24-58.2610W

Latitude:

35-04-53.3470N

35-05-02.6070N

Elevation:

315.00 ft

299.00 ft

Alignment:

79

127

Traffic Pattern:

Left

Left

Markings:

Basic, Poor Condition
RY MARKINGS FADED.

Non-precision instrument, Poor Condition
RY MARKINGS FADED.

Crossing Height:

86.00 ft

109.00 ft

Displaced threshold:

831.00 ft
RYS 08 & 26 THLDS DSPLCD NIGHTS ONLY.

1643.00 ft

VASI:

2-light PAPI on left side
PAPI OTS INDEFLY.

2-light PAPI on left side

Visual Glide Angle:

3.00°

3.00°

Runway End Identifier:



No

Obstruction:

68 ft trees, 330.0 ft from runway, 1:1 slope to clear
APCH SLOPE 17:1 FM DSPLCD THLD.
+8 FT FENCE 140 FT FM THLD BOTH SIDES; +10 FT BLAST FENCE 135 FT FM THLD.

23 ft road, 201.0 ft from runway
APCH SLOPE 50:1FM DSPLCD THLD.
+8 FT FENCE ACROSS 80 FT L 30 FT R BOTH SIDES (DIAGONAL); LGTD POLES AT THLD.

Runway 18/36

Dimension:

3278 x 60 ft / 999.1 x 18.3 m

Surface:

ASPH, Fair Condition

Weight Limit:

Single wheel: 12000 lbs.

Edge Lights:

Medium
NSTD MIRL; THLD LGTS NSTD.
MIRL OTS INDEFLY.



Runway 18

Runway 36

Longitude:

092-25-28.4730W

092-25-30.7160W

Latitude:

35-04-58.2790N

35-04-25.9090N

Elevation:

306.00 ft

315.00 ft

Alignment:

127

3

Traffic Pattern:

Left

Left

Markings:

Basic, Fair Condition

Basic, Fair Condition

Displaced threshold:

155.00 ft

0.00 ft

Obstruction:

60 ft trees, 1100.0 ft from runway, 15:1 slope to clear
APCH SLOPE 20:1 FM DSPLCD THR.

98 ft bldg, 2191.0 ft from runway, 20:1 slope to clear
+15 FT TREES 50 FT FM THLD 70 FT L; 6 FT BRUSH 50 FT FM THLD 70 FT WEST.

Radio Navigation Aids

ID

Type

Name

Ch

Freq

Var

Dist

CWS

NDB

Conway



302.00

05E

0.2 nm

BDQ

NDB

Bridge



208.00

04E

14.6 nm

TYV

NDB

Toneyville



290.00

04E

21.4 nm

MPJ

NDB

Morrilton



410.00

07E

24.7 nm

HBZ

NDB

Heber Springs



256.00

03E

33.0 nm

RUE

NDB

Russellville



379.00

03E

34.6 nm

SRC

NDB

Searcy



323.00

02E

34.9 nm

MVQ

NDB

Malvern



215.00

04E

47.9 nm

SGT

NDB

Stuttgart



269.00

02E

48.1 nm

INY

NDB

Independence County



317.00

03E

48.8 nm

VLX

NDB

Wilcox



348.00

02E

50.0 nm

LRF

TACAN

Jacksonville

029X



04E

16.4 nm

HOT

VOR/DME

Hot Springs

037X

110.00

04E

48.9 nm

LIT

VORTAC

Little Rock

086X

113.90

05E

27.1 nm

Remarks

  • LGTD +98 FT FEED MILL 2191 FT FROM END OF RY 36.
  • 170 FT AGL CRANE 3/4 MI SOUTH OF RY 36.
  • NUMEROUS AGRICULTURAL OPNS FEB-NOV.
  • 5 FT DROP OFF 100 FT SOUTH OF RY 36.

Dennis F Cantrell Field Airport

Address: Faulkner County, AR

Tel: 501-327-4559


Images and information placed above are from
http://www.airport-data.com/airport/CWS
We thank them for the data!


General Info

Country

United States

State

ARKANSAS

FAA ID

CWS

Latitude

35.080808
35° 04' 50.91" N

Longitude

-92.424961
092° 25' 29.86" W

Elevation

315 feet
96 meters

Near City

Conway






We don't guarantee the information is fresh and accurate. The data may be wrong or outdated.
For more up-to-date information please refer to other sources.
