Springdale Municipal Airport



Springdale Municipal Airport
IATA: SPZ – ICAO: KASG – FAA LID: ASG
Summary
Airport type Public
Operator City of Springdale
Location Springdale, Arkansas
Elevation AMSL 1,353 ft / 412.4 m
Coordinates 36°10′35″N 94°07′09″W / 36.17639°N 94.11917°W / 36.17639; -94.11917Coordinates: 36°10′35″N 94°07′09″W / 36.17639°N 94.11917°W / 36.17639; -94.11917
Runways
Direction Length Surface
ft m
18/36 5,302 1,616 Asphalt

Springdale Municipal Airport (IATA: SPZ, ICAO: KASG, FAA LID: ASG) is a public airport located one mile (2 km) southeast of the central business district of Springdale, a city in Washington County, Arkansas, USA. The airport covers 221 acres (89 ha) and has one runway.

Although most U.S. airports use the same three-letter location identifier for the FAA and IATA, Springdale Municipal is assigned ASG by the FAA and SPZ by the IATA (which assigned ASG to Ashburton Aerodrome in Ashburton, New Zealand). The airport's ICAO identifier is KASG.



The above content comes from Wikipedia and is published under free licenses – click here to read more.



Springdale Municipal Airport

Location & QuickFacts

FAA Information Effective:

2005-10-27

Airport Identifier:

ASG

Longitude/Latitude:

094-07-09.3300W/36-10-35.0780N
-94.119258/36.176411 (Estimated)

Elevation:

1353 ft / 412.39 m (Surveyed)

Land:

221 acres

From nearest city:

1 nautical miles SE of Springdale, AR

Location:

Washington County, AR

Magnetic Variation:

04E (1995)

Owner & Manager

Ownership:

Publicly owned

Owner:

City Of Springdale

Address:

City Hall, 201 Spring St
Springdale, AR 72764

Phone number:

479-750-8114

Manager:

James Smith

Address:

802 Airport Road
Springdale, AR 72765

Phone number:

479-750-8585

Airport Operations and Facilities

Airport Use:

Open to public

Wind indicator:

Yes

Segmented Circle:

Yes

Control Tower:

Yes

Attendance Schedule:

ALL/ALL/0600-2200
FOR SVC AFT HRS CALL 479-751-4462.

Lighting Schedule:

DUSK-DAWN
ACTVT HIRL RY 18/36 - CTAF. WHEN ATCT CLSD ACTVT MALSF RY 18 - CTAF.

Beacon Color:

Clear-Green (lighted land airport)

Landing fee charge:

No

Sectional chart:

Kansas City

Region:

ASW - Southwest

Boundary ARTCC:

ZME - Memphis

Tie-in FSS:

JBR - Jonesboro

FSS on Airport:

No

FSS Phone:

870-935-3471

FSS Toll Free:

1-800-WX-BRIEF

NOTAMs Facility:

ASG (NOTAM-d service avaliable)

Federal Agreements:

NGY

Airport Communications

CTAF:

118.200

Unicom:

122.950

Airport Services

Fuel available:

100LLA

Airframe Repair:

MAJOR

Power Plant Repair:

MAJOR

Bottled Oxygen:

NONE

Bulk Oxygen:

NONE

Runway Information

Runway 18/36

Dimension:

5302 x 75 ft / 1616.0 x 22.9 m

Surface:

ASPH, Fair Condition

Weight Limit:

Single wheel: 35000 lbs.
Dual wheel: 50000 lbs.
Dual tandem wheel: 90000 lbs.

Edge Lights:

High



Runway 18

Runway 36

Longitude:

094-07-05.2994W

094-07-13.2842W

Latitude:

36-11-01.0511N

36-10-09.0275N

Elevation:

1339.00 ft

1352.00 ft

Alignment:

127

7

ILS Type:

ILS



Traffic Pattern:

Left

Left

Markings:

Precision instrument, Fair Condition
CENTERLINE MARKING FADED.

Precision instrument, Fair Condition

Crossing Height:

34.00 ft

36.00 ft

Displaced threshold:

363.00 ft

0.00 ft

VASI:

2-box on left side

2-box on left side

Visual Glide Angle:

3.00°

3.00°

Approach lights:

MALSF
SFL OTS INDEFLY.



Obstruction:

, 50:1 slope to clear
APCH RATIO 50:1 FM DSPLCD THR.

14 ft trees, 700.0 ft from runway, 600 ft right of centerline, 35:1 slope to clear

Radio Navigation Aids

ID

Type

Name

Ch

Freq

Var

Dist

SLG

NDB

Siloam Springs



284.00

04E

17.9 nm

TQH

NDB

Tahlequah



215.00

05E

45.6 nm

DAK

VOR/DME

Drake

025X

108.80

07E

8.9 nm

EOS

VOR/DME

Neosho

120X

117.30

07E

42.9 nm

HRO

VOR/DME

Harrison

072X

112.50

04E

44.7 nm

RZC

VORTAC

Razorback

111X

116.40

04E

4.2 nm

FSM

VORTAC

Fort Smith

041X

110.40

07E

47.9 nm

Remarks

  • BIRD ACTIVITY INVOF ARPT DURG MORNING & EVENING HRS.

Springdale Municipal Airport

Address: Washington County, AR

Tel: 479-750-8585


Images and information placed above are from
http://www.airport-data.com/airport/ASG/
We thank them for the data!


General Info

Country

United States

State

ARKANSAS

FAA ID

ASG

Latitude

36-10-35.078N

Longitude

094-07-09.330W

Elevation

1353 feet

Near City

SPRINGDALE






We don't guarantee the information is fresh and accurate. The data may be wrong or outdated.
For more up-to-date information please refer to other sources.
