Calexico International Airport |
| Calexico International Airport |
| IATA: CXL – ICAO: KCXL – FAA LID: CXL |
| Summary |
| Airport type |
Public |
| Owner |
City of Calexico |
| Serves |
Calexico, California |
| Elevation AMSL |
4 ft / 1 m |
| Coordinates |
Coordinates: 32°40′10″N 115°30′48″W / 32.66944°N 115.51333°W / 32.66944; -115.51333 |
| Runways |
| Direction |
Length |
Surface |
| ft |
m |
| 8/26 |
4,679 |
1,426 |
Asphalt |
| Statistics (2004) |
| Aircraft operations |
12,240 |
| Based aircraft |
23 |
| Source: Federal Aviation Administration |
Calexico International Airport (IATA: CXL, ICAO: KCXL, FAA LID: CXL) is a city-owned public-use airport located one mile (1.6 km) west of the central business district of Calexico, in Imperial County, California, United States. The airport is mostly used for general aviation and to facilitate border crossing.
Facilities and aircraft
Calexico International Airport covers an area of 257 acres (104 ha) which contains one asphalt paved runway (8/26) measuring 4,679 x 75 ft (1,426 x 23 m). For the 12-month period ending December 31, 2004, the airport had 12,240 aircraft operations, an average of 33 per day: 93% general aviation and 7% air taxi. At that time there were 23 aircraft based at this airport: 83% single-engine and 17% multi-engine.
The above content comes from Wikipedia and is published under free licenses – click here to read more.
Location
& QuickFacts
|
FAA Information Effective: |
2006-06-08 |
|
Airport Identifier: |
CXL |
|
Longitude/Latitude: |
115-30-47.9810W/32-40-10.2120N
-115.513328/32.669503 (Estimated) |
|
Elevation: |
4 ft / 1.22 m (Estimated) |
|
Land: |
257 acres |
|
From nearest city: |
1 nautical miles W of Calexico, CA |
|
Location: |
Imperial County, CA |
|
Magnetic Variation: |
13E (1985) |
Owner
& Manager
|
Ownership: |
Publicly owned |
|
Owner: |
City Of Calexico |
|
Address: |
608 Heber Avenue
Calexico, CA 92231 |
|
Phone
number: |
760-768-2180 |
|
Manager: |
Luis Estrada
THE OFFICE OF THE DIRECTOR OF PUBLIC WORKS IS IN CALEXICO. |
|
Address: |
608 Heber Avenue
Calexico, CA 92231 |
|
Phone number: |
760-768-2175 |
Airport
Operations and Facilities
|
Airport
Use: |
Open to public |
|
Wind
indicator: |
Yes |
|
Segmented
Circle: |
Yes |
|
Control
Tower: |
No |
|
Attendance
Schedule: |
ALL/ALL/0800-1700 |
|
Lighting
Schedule: |
DUSK-DAWN |
|
Beacon
Color: |
Clear-Green (lighted land airport) |
|
Landing
fee charge: |
No |
|
Sectional
chart: |
Phoenix |
|
Region: |
AWP - Western-Pacific |
|
Boundary
ARTCC: |
ZLA - Los Angeles |
|
Tie-in
FSS: |
SAN - San Diego |
|
FSS
on Airport: |
No |
|
FSS
Phone: |
858-277-7043 |
|
FSS
Toll Free: |
1-800-WX-BRIEF |
|
NOTAMs
Facility: |
SAN (NOTAM-d service avaliable) |
|
Federal Agreements: |
NGY |
Airport
Communications
|
CTAF: |
122.800 |
|
Unicom: |
122.800
UNICOM MONITORED 0800-1700. |
Airport
Services
|
Fuel
available: |
100LLA |
|
Airframe
Repair: |
NONE |
|
Power
Plant Repair: |
NONE |
|
Bulk
Oxygen: |
NONE |
|
Runway Information
Runway 08/26
|
Dimension: |
4679 x 75 ft / 1426.2 x 22.9 m |
|
Surface: |
ASPH, Good Condition |
|
Weight
Limit: |
Single wheel: 30000 lbs. |
|
Edge
Lights: |
Medium |
|
|
Runway 08 |
Runway 26 |
|
Longitude: |
115-31-30.6500W |
115-30-35.9200W |
|
Latitude: |
32-40-03.2200N |
32-40-02.2700N |
|
Elevation: |
0.00 ft |
6.00 ft |
|
Traffic
Pattern: |
Left |
Right |
|
Markings: |
Basic, Good Condition |
Basic, Good Condition |
|
Crossing
Height: |
33.00 ft |
39.00 ft |
|
Displaced
threshold: |
0.00 ft |
163.00 ft |
|
VASI: |
2-box on left side |
2-box on left side |
|
Visual
Glide Angle: |
3.00° |
3.40° |
|
Runway
End Identifier: |
No |
No |
|
Centerline
Lights: |
No |
No |
|
Touchdown
Lights: |
No |
No |
|
Obstruction: |
37 ft pline, 1350.0 ft from runway, 31:1 slope
to clear |
, 50:1 slope to clear |
|
Radio Navigation
Aids
|
ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
|
NJK |
TACAN |
El Centro |
047X |
|
13E |
12.9 nm |
|
NYL |
TACAN |
Yuma |
084X |
|
14E |
45.6 nm |
|
MXL |
VOR/DME |
Mexicali |
097X |
115.00 |
14E |
14.9 nm |
|
IPL |
VORTAC |
Imperial |
106X |
115.90 |
14E |
4.8 nm |
|
BZA |
VORTAC |
Bard |
115X |
116.80 |
14E |
46.4 nm |
Remarks
Based Aircraft
|
Aircraft
based on field: |
23 |
|
Single
Engine Airplanes: |
19 |
|
Multi
Engine Airplanes: |
4 |
Operational Statistics
|
Aircraft
Operations: |
236/Week |
|
Air Taxi: |
7.2% |
|
General
Aviation Local: |
22.2% |
|
General
Aviation Itinerant: |
70.6% |
Calexico International Airport
Address:
Imperial County, CA
Tel:
760-768-2180,
760-768-2175
Images
and information placed above are from
http://www.airport-data.com/airport/CXL/
We
thank them for the data!
| General
Info |
| Country |
United
States |
| State |
CALIFORNIA
|
| FAA ID |
CXL
|
| Latitude |
32-40-10.212N
|
| Longitude |
115-30-47.981W
|
| Elevation |
4 feet
|
| Near City |
CALEXICO
|
We don't guarantee the information is fresh and accurate. The data may
be wrong or outdated.
For more up-to-date information please refer to other sources.
|
|
