Dobbins Air Reserve Base (Atlanta Nas) Airport |
|
|
Location
& QuickFacts
|
FAA Information Effective: |
2007-01-18 |
|
Airport
Identifier: |
MGE |
|
Airport
Status: |
Operational |
|
Longitude/Latitude: |
084-30-58.8000W/33-54-55.2000N
-84.516333/33.915333 (Estimated) |
|
Elevation: |
1068 ft / 325.53 m (Surveyed) |
|
Land: |
0
acres |
|
From
nearest city: |
1 nautical miles S of Marietta, GA |
|
Location: |
Cobb County, GA |
|
Magnetic Variation: |
02W (1985) |
Owner
& Manager
|
Ownership: |
Air Force owned |
|
Owner: |
Usaf |
|
Address: |
Dobbins Afb
Marietta, GA 30060 |
|
Manager: |
Chief Of Afld Management |
|
Address: |
Dobbins Afb
Marietta, GA 30060 |
Airport
Operations and Facilities
|
Airport Use: |
Private |
|
Wind
indicator: |
Yes |
|
Segmented
Circle: |
No |
|
Control
Tower: |
Yes |
|
Lighting
Schedule: |
DUSK-DAWN |
|
Beacon
Color: |
Clear-Green (lighted land airport) |
|
Sectional
chart: |
Atlanta |
|
Region: |
ASO - Southern |
|
Boundary
ARTCC: |
ZTL - Atlanta |
|
Tie-in
FSS: |
MCN - Macon |
|
FSS
on Airport: |
No |
|
FSS
Phone: |
478-784-1155 |
|
FSS
Toll Free: |
1-800-WX-BRIEF |
|
NOTAMs
Facility: |
MGE (NOTAM-d service avaliable) |
|
Certification type/date: |
I A U 04/1975 |
Airport
Services
|
Fuel available: |
100LL115 B+ |
|
Airframe Repair: |
MAJOR |
|
Power Plant Repair: |
MAJOR |
|
Bottled
Oxygen: |
NONE |
|
Bulk
Oxygen: |
HIGH/LOW |
|
Runway Information
Runway 11/29
|
Dimension: |
10000 x 300 ft / 3048.0 x 91.4 m |
|
Surface: |
CONC, |
|
Pavement
Class: |
83 /R/B/W/T |
|
Weight
Limit: |
Single wheel: 200000 lbs.
Dual wheel: 300000 lbs.
Dual
tandem wheel: 560000 lbs. |
|
Edge
Lights: |
High |
|
|
Runway 11 |
Runway 29 |
|
Longitude: |
084-31-55.8290W |
084-30-01.8980W |
|
Latitude: |
33-55-08.8260N |
33-54-41.1660N |
|
Elevation: |
1068.00
ft |
989.00
ft |
|
Alignment: |
106 |
127 |
|
ILS
Type: |
LOC/GS |
LOC/GS |
|
Traffic
Pattern: |
Left |
Left |
|
Arresting: |
E28 |
E28 |
|
VASI: |
4-light PAPI on left side |
4-light PAPI on left side |
|
RVR
Equipment: |
touchdown |
touchdown |
|
Approach
lights: |
ALSF1 |
SALSF |
|
Runway
End Identifier: |
No |
Yes |
|
Centerline
Lights: |
No |
No |
|
Touchdown
Lights: |
No |
No |
|
Runway 110/290
|
Dimension: |
4000 x 60 ft / 1219.2 x 18.3 m |
|
Surface: |
ASPH, |
|
Pavement
Class: |
43 /R/C/W/T |
|
Edge
Lights: |
High |
|
|
Runway 110 |
Runway 290 |
|
Traffic
Pattern: |
Left |
Left |
|
Radio Navigation
Aids
|
ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
|
FT |
NDB |
Flanc |
|
344.00 |
02W |
11.0 nm |
|
BR |
NDB |
Redan |
|
266.00 |
02W |
19.2 nm |
|
DJD |
NDB |
Canton |
|
415.00 |
04W |
20.3 nm |
|
EVZ |
NDB |
Cartersville |
|
308.00 |
04W |
23.6 nm |
|
JZP |
NDB |
Pickens County |
|
285.00 |
04W |
32.6 nm |
|
FKV |
NDB |
Flowery Branch |
|
365.00 |
03W |
35.0 nm |
|
OUK |
NDB |
Calhoun |
|
323.00 |
02W |
35.6 nm |
|
FF |
NDB |
Pecat |
|
316.00 |
02W |
37.0 nm |
|
GPQ |
NDB |
Carrollton |
|
278.00 |
02W |
37.2 nm |
|
OYD |
NDB |
Floyd |
|
388.00 |
02W |
39.6 nm |
|
VOF |
NDB |
Alcovy |
|
370.00 |
03W |
40.5 nm |
|
EQQ |
NDB |
Coweta County |
|
234.00 |
03W |
40.8 nm |
|
JNM |
NDB |
Monroe |
|
392.00 |
03W |
40.8 nm |
|
BMW |
NDB |
Barrow County |
|
404.00 |
03W |
46.2 nm |
|
JHH |
NDB |
Griffin |
|
412.00 |
04W |
46.3 nm |
|
DOB |
TACAN |
Dobbins |
077X |
|
01W |
0.5 nm |
|
PDK |
VOR/DME |
Peachtree |
113X |
116.60 |
02W |
11.1 nm |
|
ATL |
VORTAC |
Atlanta |
116X |
116.90 |
00W |
17.7 nm |
|
RMG |
VORTAC |
Rome |
101X |
115.40 |
01E |
33.5 nm |
|
ATL |
VOT |
Atlanta Muni |
|
111.00 |
|
16.1 nm |
Remarks
- LGT:
FOR OLS RWY 11-29 LCTN DATA SEE FLIP AP/1 SUPPLEMENTARY ARPT RMK.
- A-GEAR:
E-28(B) IN RAISED POSN ON DEP END OF ACTIVE RWY. E-28 RQR 20 MIN PN
FOR APCH END ENGAGEMENT. E-28
DEP END RWY 29 O/S UFN.
- JASU
AF: 1(A/MA32A-86) 2(AM32-95) 1(AM32A-60A)
- JASU
NAVY: 1(A/M47A-4) 1(NC-10)
- FUEL:
OPR 1130-0430Z++. TRAN ACFT EXP 1 HR FUEL DELAY. J8,
J8+100. LHNIT
- FUEL
NAVY: OPR 1000-2000Z++ MON-SUN. CLSD
HOL. J8
- FLUID:
SP PRESAIR LOX LPOX LPNIT NO DE-ICE AVBL FOR TRAN ACFT.
- OIL:
O-148-156 SOAP/JOAP, NO LAB SVC.
- TRAN
ALERT: OPR 1200-0400Z++ MON-SUN.
- TRAN
ALERT NAVY: MULTI ACFT EXP 1-2 HR FUEL DELAY. CLSD HOL. FLUID &
OIL UNAVBL.
- ARNG:
ACFT/AIRCREWS DESIRING TO VISIT AASF#2, CTC DSN 625-5287 PRIOR TO ARR.
- AR:
CTC C678-655-5284/5, 132.95. NO TRAN FUEL/SVC. LTD RAMP SPACE, PRIOR
COORD RQR TO USE ASF RAMP.
- MISC
NAVY: ACFT FILING TO ATLANTA NAS, LIST MGE AS DESTN ON DD175 AND NCQ
IN RMK SEC. CTC BASE OPS 20 MIN PRIOR LDG TO CONFIRM PPR AND SVCG/LOAD.
- RSTD
NAVY: PPR, DSN 625-6359.
- CAUTION:
ALL ACFT RADAR MUST BE IN SBY STATUS WHILE USING TWY E. OBST APRX 5'
AGL E-28 BARRIER BRAKE SYS, LCTD 20' FR RWY EDGE.
- RSTD:
PPR DSN 625-4903, C678-655-4903. ACFT RSTD DUR BIRD WATCH COND MODERATE
(TKOF/LDG PERMS WHEN DEP/ARR RTE AVOID IDENT BIRD ACT, NO LCL IFR/VFR
TFC PAT ACFT) AND SEVERE (TKOF/LDG PROH WO 94TH OG/CC APVL), CTC BASE
OPS FOR CURRENT BIRD WATCH COND.
- RSTD:
HAZ CARGO RSTD TO C130 OR SMALLER ACFT, 24 HR PN RQR. DO NOT TRANS ON
HF WO TWR APVL. TO PRK AF SIDE PPR, DSN 625-4903. AFLD OFFL BUS ONLY
0400-1200Z++. ASSAULT
LDG ZONE LCL USE ONLY.
- MISC:
WINDS ARE EST DUE TO FMQ-13 WIND SENSORS BEING ACCURATE TO WITHIN ONLY
+/-4 KT. ATC/WX WILL NOT INCL/RELAY WIND CORR INTO FCST/PHRASEOLOGY.
THEREFORE, AIRCREWS WILL INCORPORATE A +/- 4 KT ACCURACY INTO THEIR
DECISION MAKING PROCESS FOR FLYING OPR.
- MISC:
LTD TRAN 1200-2100Z++ WKD. ALL OT MUST BE COORD WITH TRAN 24 HR PN WKD.
THIS INCL ON/OFF BASE AND TO/FR FLT LINE CTC DSN 625-3667. BASE OPS
DOES NOT HAVE COMSEC AVBL FOR TRANS CREWS AND HAS NO STOR CAPABILITIES.
RSRS APPLIED TO BASE ASGN ACFT ONLY; STD USAF RSRS NOT APPLICABLE.
- MISC:
BASE OPS FAX DSN 625-4915.
- RADAR:
SEE TERMINAL FLIP FOR RADAR MINIMA.
- MISC:
RY 29 NON-STD APCH LIGHTS, STATION 1+00 NOT INSTALLED, STATION 2+00
CENTER LIGHT WRONG COLOR LENS.
- EXPOSED
CONC FOUNDATIONS 3-5 FT HIGH IN EAST & WEST CLEAR ZONE AT APCH LGTS.
- OIL:
NO LAB SVC.
- MISC:
COMSEC STOR 30 MIN PN RQR, CTC DSN 625-5154 MON-FRI AND UNIT TRNG WKEND
1230-2130Z++, OT 2 HR PN AFTER DUTY HRS CTC C678-614-4252.
Operational Statistics
|
Aircraft
Operations: |
240/Day |
|
Military: |
100.0% |
Dobbins Air Reserve Base (atlanta Nas)
Airport
Address:
Cobb County, GA
Tel:
Images
and information placed above are from
http://www.airport-data.com/airport/MGE/
We
thank them for the data!
| General
Info |
| Country |
United
States |
| State |
GEORGIA
|
| FAA ID |
MGE
|
| Latitude |
33-54-55.370N
|
| Longitude |
084-30-58.754W
|
| Elevation |
1068 feet
|
| Near City |
MARIETTA
|
We don't guarantee the information is fresh and accurate. The data may
be wrong or outdated.
For more up-to-date information please refer to other sources.
|
|
