Dept Of Corrections Heliport

Dept Of Corrections Heliport picture

Location & QuickFacts

FAA Information Effective:

2007-07-05

Airport Identifier:

8IS3

Airport Status:

Operational

Longitude/Latitude:

090-27-40.4180W/38-58-24.1740N
-90.461227/38.973382 (Estimated)

Elevation:

450 ft / 137.16 m (Estimated)

Land:

0 acres

From nearest city:

0 nautical miles W of Grafton, IL

Location:

Jersey County, IL

Magnetic Variation:

02E (1985)

Owner & Manager

Ownership:

Publicly owned

Owner:

State Of Illinois

Address:

2200 West Main Street
Grafton, IL 62037

Phone number:

618-786-2371

Manager:

Gary L. Mchugh

Address:

2200 West Main Street
Grafton, IL 62037

Phone number:

618-786-2371

Airport Operations and Facilities

Airport Use:

Private

Wind indicator:

Yes

Segmented Circle:

No

Control Tower:

No

Sectional chart:

St Louis

Region:

AGL - Great Lakes

Boundary ARTCC:

ZKC - Kansas City

Tie-in FSS:

STL - Saint Louis

FSS on Airport:

No

FSS Phone:

636-536-2980

FSS Toll Free:

1-800-WX-BRIEF

Runway Information

Helipad H1

Dimension:

30 x 30 ft / 9.1 x 9.1 m

Surface:

CONC,



Runway H1

Runway

Traffic Pattern:

Left

Left



Radio Navigation Aids

ID

Type

Name

Ch

Freq

Var

Dist

LM

NDB

Oblio



338.00

00E

10.4 nm

CVM

NDB

Civic Memorial



263.00

02E

19.6 nm

LTD

NDB

Litchfield



371.00

01E

38.4 nm

PPQ

NDB

Pittsfield



344.00

02E

42.8 nm

BL

NDB

Belleville



362.00

02E

45.0 nm

FES

NDB

Festus



269.00

01E

46.9 nm

SKE

TACAN

Scott

059X



02E

38.4 nm

CSX

VOR/DME

Cardinal

111Y

116.45

00E

14.1 nm

IJX

VOR/DME

Jacksonville

023X

108.60

02E

49.4 nm

STL

VORTAC

St Louis

121X

117.40

01E

6.8 nm

TOY

VORTAC

Troy

107X

116.00

04E

29.0 nm

FTZ

VORTAC

Foristell

045X

110.80

05E

29.2 nm

STL

VOT

St Louis Lambert



111.00



14.3 nm

SUS

VOT

Spirit Of St Louis



112.20



20.7 nm

Remarks

  • PRVDD APP/DEP OPNS ARE CONDD IN AN AREA FM 130-170 & 340-010 DEG, AREA IS MKD, WIND INDCR IS MAINTD.



Dept Of Corrections Heliport

Address: Jersey County, IL

Tel: 618-786-2371


Images and information placed above are from
http://www.airport-data.com/airport/8IS3/

We thank them for the data!




General Info
Country United States
State ILLINOIS
FAA ID 8IS3
Latitude 38-58-24.174N
Longitude 090-27-40.418W
Elevation 450 feet
Near City GRAFTON



We don't guarantee the information is fresh and accurate. The data may be wrong or outdated.
For more up-to-date information please refer to other sources.
