Location & QuickFacts
| FAA Information Effective: | 2008-09-25 |
| Airport Identifier: | 80D |
| Airport Status: | Operational |
| Longitude/Latitude: | 084-48-45.0870W/44-03-10.0680N
-84.812524/44.052797 (Estimated) |
| Elevation: | 1142 ft / 348.08 m (Estimated) |
| Land: | 80 acres |
| From nearest city: | 2 nautical miles NW of Harrison, MI |
| Location: | Clare County, MI |
| Magnetic Variation: | 05W (1985) |
Owner & Manager
| Ownership: | Publicly owned |
| Owner: | County Of Clare |
| Address: | Po Box 438
Harrison, MI 48625 |
| Phone number: | 989-539-2510 |
| Manager: | Ron Spencer |
| Address: | P.o. Box 856
Harrison, MI 48625 |
| Phone number: | 989-205-4142 |
Airport Operations and Facilities
| Airport Use: | Open to public |
| Wind indicator: | Yes |
| Segmented Circle: | Yes |
| Control Tower: | No |
| Lighting Schedule: | DUSK-DAWN |
| Beacon Color: | Clear-Green (lighted land airport) |
| Landing fee charge: | No |
| Sectional chart: | Lake Huron |
| Region: | AGL - Great Lakes |
| Boundary ARTCC: | ZMP - Minneapolis |
| Tie-in FSS: | LAN - Lansing |
| FSS on Airport: | No |
| FSS Toll Free: | 1-800-WX-BRIEF |
| NOTAMs Facility: | LAN (NOTAM-d service avaliable) |
Airport Communications
| CTAF: | 122.800 |
| Unicom: | 122.800 |
Airport Services
| Airframe Repair: | NONE |
| Power Plant Repair: | NONE |
| Bottled Oxygen: | NONE |
| Bulk Oxygen: | NONE |
Runway Information
Runway 09/27
| Dimension: | 2437 x 100 ft / 742.8 x 30.5 m |
| Surface: | TURF, Poor Condition
SFC ROUGH. |
| |
Runway 09 |
Runway 27 |
| Longitude: | 084-49-01.1100W | 084-48-29.4900W |
| Latitude: | 44-03-17.6400N | 44-03-15.9400N |
| Elevation: | 1142.00 ft | 1142.00 ft |
| Traffic Pattern: | Left | Left |
| Displaced threshold: | 1218.00 ft | 882.00 ft |
| Touchdown Lights: | No | No |
| Obstruction: | 70 ft trees, 182.0 ft from runway, 3:1 slope to clear
APCH RATIO 21:1 AT DSPLCD THLD. | 65 ft trees, 180.0 ft from runway, 100 ft right of centerline, 3:1 slope to clear
APCH RATIO 12:1 AT DSPLCD THLD. OVR +87 FT TREE, 1062 FT FM DSPLCD THR, 130 FT R |
|
Runway 18/36
| Dimension: | 2978 x 50 ft / 907.7 x 15.2 m |
| Surface: | ASPH, Good Condition
SFC ROUGH. |
| Edge Lights: | Non-standard lighting system
NSTD LIRL; 30 FT FM RY EDGE & NO RY END LGTS. ACTVT LGTS - 122.8. |
| |
Runway 18 |
Runway 36 |
| Longitude: | 084-48-44.5400W | 084-48-45.2100W |
| Latitude: | 44-03-17.3500N | 44-02-49.9000N |
| Elevation: | 1142.00 ft | 1142.00 ft |
| Traffic Pattern: | Left | Left |
| Markings: | Basic, Fair Condition | Basic, Fair Condition |
| Displaced threshold: | 473.00 ft | 1152.00 ft |
| Runway End Identifier: | No | No |
| Centerline Lights: | No | No |
| Touchdown Lights: | No | No |
| Obstruction: | 41 ft trees, 350.0 ft from runway, 135 ft right of centerline, 3:1 slope to clear
APCH RATIO 12:1 AT DSPLCD THLD. | 68 ft trees, 208.0 ft from runway
APCH RATIO 4:1 AT DSPLCD THLD, OVR +60 FT TREES, 240 FT FRM DSPLCD THR, 150 FT R.
4 FT FENCE 75 FT FM THLD L/R, 30 FT PLINE 177 FT FM THLD L/R. +68 FT TREES, 201 FM THLD, L/R. |
|
Radio Navigation Aids
| ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
| GDW | NDB | Wiggins | | 209.00 | 04W | 15.4 nm |
| CAD | NDB | Cadillac | | 269.00 | 04W | 29.2 nm |
| BHW | NDB | Hardwood | | 236.00 | 06W | 33.6 nm |
| GYG | NDB | Grayling | | 359.00 | 06W | 41.9 nm |
| AMN | NDB | Alma | | 329.00 | 05W | 43.9 nm |
| TV | NDB | Gwenn | | 365.00 | 05W | 48.8 nm |
| CGG | VOR | Grayling | | 109.80 | 06W | 38.0 nm |
| HTL | VOR/DME | Houghton Lake | 053X | 111.60 | 05W | 19.5 nm |
| MOP | VOR/DME | Mount Pleasant | 043X | 110.60 | 05W | 26.1 nm |
| BXZ | VOR/DME | West Branch | 079X | 113.20 | 06W | 29.4 nm |
| MBS | VOR/DME | Saginaw | 076X | 112.90 | 03W | 44.7 nm |
| HIC | VOR/DME | White Cloud | 123X | 117.60 | 01W | 48.6 nm |
| TVC | VORTAC | Traverse City | 093X | 114.60 | 02W | 48.7 nm |
Remarks
- RY 09/27 CLSD WINTER MONTHS.
- RDO CTL MODEL ACFT & ULTRALGT ACTIVITY ON & INVOF ARPT.
- DEER ON & INVOF ARPT.
- RY 27, 22 FT POWERLINE, 308 FT DSTC, APCH RATIO 14:1. POWERLINE MKD WITH ORANGE BALLS
