Location & QuickFacts
| FAA Information Effective: | 2008-09-25 |
| Airport Identifier: | 3GV |
| Airport Status: | Operational |
| Longitude/Latitude: | 094-12-47.8090W/39-00-56.0240N
-94.213280/39.015562 (Estimated) |
| Elevation: | 835 ft / 254.51 m (Estimated) |
| Land: | 120 acres |
| From nearest city: | 0 nautical miles N of Grain Valley, MO |
| Location: | Jackson County, MO |
| Magnetic Variation: | 03E (2000) |
Owner & Manager
| Ownership: | Privately owned |
| Owner: | Grain Valley Airport Corp |
| Address: | Box 255 Walnut & Kirby Rd
Grain Valley, MO 64029 |
| Phone number: | 816-229-8868 |
| Manager: | Richard And Dionne White |
| Address: | Box 255, Walnut & Kirby Rd
Grain Valley, MO 64029 |
| Phone number: | 816-847-8553
AFTR HRS 816-588-2807 |
Airport Operations and Facilities
| Airport Use: | Open to public |
| Wind indicator: | Yes |
| Segmented Circle: | No
RIGHT TRAFFIC INDICATORS WITH WIND TEE ONLY. |
| Control Tower: | No |
| Lighting Schedule: | DUSK-DAWN
ACTVT MIRL RY 09/27; VASI RYS 09 & 27; REIL RY 09 - CTAF. |
| Beacon Color: | Clear-Green (lighted land airport) |
| Landing fee charge: | No |
| Sectional chart: | Kansas City |
| Region: | ACE - Central |
| Boundary ARTCC: | ZKC - Kansas City |
| Tie-in FSS: | COU - Columbia |
| FSS on Airport: | No |
| FSS Toll Free: | 1-800-WX-BRIEF |
| NOTAMs Facility: | COU (NOTAM-d service avaliable) |
Airport Communications
| CTAF: | 122.800 |
| Unicom: | 122.800 |
Airport Services
| Fuel available: | 100LLA |
| Airframe Repair: | MINOR |
| Power Plant Repair: | MINOR |
| Bottled Oxygen: | NONE |
| Bulk Oxygen: | NONE |
Runway Information
Runway 05/23
| Dimension: | 2200 x 20 ft / 670.6 x 6.1 m
RWY 05/23 STEEP SLOPE 60-235 FT NE OF RWY 05 THLD.
WIDTH VARIANCE 20-25 FT.
WIDTH VARIANCE 44-45 FT. |
| Surface: | ASPH, Good Condition
CRACKS WITH GRASS AND WEEDS GROWING IN THEM. |
| Weight Limit: | Single wheel: 11000 lbs. |
| |
Runway 05 |
Runway 23 |
| Longitude: | 094-12-59.2000W | 094-12-35.6900W |
| Latitude: | 39-00-50.6600N | 39-01-02.4500N |
| Elevation: | 818.00 ft | 834.00 ft |
| Traffic Pattern: | Left | Right |
| Markings: | Nonstandard, Fair Condition
RWY 05 NSTD BSC MARKINGS; SMALL NRS; INCORRECT SIZE & SPACING OF CNTRLN. | Nonstandard, Fair Condition
RWY 23 NSTD NPI MARKINGS; SMALL NRS; NO THLD BARS & INCORRECT SIZE & SPACING OF CNTRLN. |
| Obstruction: | 20 ft rr, 225.0 ft from runway, 107 ft right of centerline, 1:1 slope to clear | 53 ft tree, 656.0 ft from runway, 207 ft right of centerline, 8:1 slope to clear |
|
Runway 09/27
| Dimension: | 4501 x 44 ft / 1371.9 x 13.4 m
RWY 05/23 STEEP SLOPE 60-235 FT NE OF RWY 05 THLD.
WIDTH VARIANCE 20-25 FT.
WIDTH VARIANCE 44-45 FT. |
| Surface: | ASPH, Fair Condition
CRACKS WITH GRASS AND WEEDS GROWING IN THEM. |
| Surface Treatment: | Aggregate Friction Seal Coat |
| Weight Limit: | Single wheel: 11000 lbs. |
| Edge Lights: | Non-standard lighting system
RWY 09/27 NSTD MIRL; NO YELLOW EDGE LGTS LAST 2000 FT RY 27 & RY 09; ALL EDGE LGTS LCTD 13-15 FT FM PAVEMENT EDGE; ONLY 6 THLD LGTS RY 27 & LCTD 18-20 FT E OF THLD. |
| |
Runway 09 |
Runway 27 |
| Longitude: | 094-13-24.9900W | 094-12-27.9100W |
| Latitude: | 39-00-51.3200N | 39-00-50.3300N |
| Elevation: | 817.00 ft | 818.00 ft |
| Alignment: | 91 | 127 |
| Traffic Pattern: | Right | Left |
| Markings: | Nonstandard, Fair Condition
RWY 09 NSTD PIR MARKINGS; NO AIMING POINT; SMALL RY THLD; TOUCHDOWN & CNTRLN MARKINGS & INCORRECT SPACING. | Nonstandard, Fair Condition
RWY 27 NSTD PIR MARKINGS; NO AIMING POINT; SMALL RY THLD; TOUCHDOWN & CNTRLN MARKINGS & INCORRECT SPACING. |
| Crossing Height: | 32.00 ft | 46.00 ft |
| Displaced threshold: | 300.00 ft
RWY 09 NSTD DSPLCD THLD MARKINGS; SMALL ARROW HEAD; INCORRECT SPACING OF ARROWS & THLD BAR. | 0.00 ft |
| VASI: | 4-box on left side | 4-box on left side |
| Visual Glide Angle: | 4.00° | 3.50° |
| Runway End Identifier: | Yes | |
| Obstruction: | 20 ft rr, 200.0 ft from runway, 200 ft right of centerline
RWY 09 0:1 TO DSPLCD THLD; +1-5 FT GND DSTC 0-90 FT 70 -130 FT R; 0:1 BASED ON DSPLCD THLD..
RWY 09 1-20 FT GND 0-200 FT FM RY END L & R; +16 FT SIGNS 165 FT FM RY END 80 FT L; 10-25 FT ROAD 0-200 FT FM RY END 125-160 FT L; +18 FT TREES & BRUSH, 60-70 FT FM RY END, 63-90 FT R; +1-50 FT TREES & RR 0-200 FT FM RY END 200-250 FT R. | 20 ft rr, 200.0 ft from runway, 190 ft left of centerline
RWY 27 +1-33 FT BRUSH; TREES; FENCE; RR; ROAD & BLDGS 0-200 FT FM RY END L & R. |
|
Runway 17/35
| Dimension: | 1230 x 25 ft / 374.9 x 7.6 m
RWY 05/23 STEEP SLOPE 60-235 FT NE OF RWY 05 THLD.
WIDTH VARIANCE 20-25 FT.
WIDTH VARIANCE 44-45 FT. |
| Surface: | ASPH, Fair Condition
CRACKS WITH GRASS AND WEEDS GROWING IN THEM. |
| |
Runway 17 |
Runway 35 |
| Traffic Pattern: | Left | Left |
| Markings: | None,
17/35 NSTD BASIC MARKINGS; SMALL NRS; INCORRECT SPACING & SMALL DASHED CNTRLN. | None, |
|
Radio Navigation Aids
| ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
| LXT | NDB | Lesumit | | 263.00 | 04E | 8.1 nm |
| GPH | NDB | Mosby | | 284.00 | 03E | 20.3 nm |
| GKB | NDB | Norge | | 517.00 | 05E | 20.8 nm |
| GQ | NDB | Norge | | 517.00 | 05E | 20.8 nm |
| DO | NDB | Dotte | | 359.00 | 05E | 27.9 nm |
| HCK | NDB | Hawks | | 296.00 | 04E | 38.0 nm |
| EZZ | NDB | Cameron | | 394.00 | 03E | 43.0 nm |
| GLY | NDB | Golden Valley | | 388.00 | 04E | 46.6 nm |
| PUR | NDB | Marshall | | 371.00 | 03E | 47.5 nm |
| SZL | TACAN | Whiteman | 035X | | 04E | 35.3 nm |
| RIS | VOR/DME | Riverside | 051X | 111.40 | 05E | 19.0 nm |
| OJC | VOR/DME | Johnson County | 077X | 113.00 | 06E | 26.6 nm |
| BQS | VOR/DME | Braymer | 049X | 111.20 | 03E | 40.2 nm |
| ANX | VORTAC | Napoleon | 087X | 114.00 | 07E | 6.2 nm |
| MCI | VORTAC | Kansas City | 079Y | 113.25 | 05E | 29.3 nm |
| BUM | VORTAC | Butler | 106X | 115.90 | 07E | 46.5 nm |
| MKC | VOT | Kansas City Downtown | | 108.60 | | 19.1 nm |
Remarks
- MIGRATORY WATERFOWL ON & INVOF ARPT.
- RY 17/35 CLSD PERMLY.
- NTSD RY SAFETY AREA LENGTHS BYD EACH RY END. INSUFFICIENT LENGTHS, INCOR TERRAIN GRADES. NO RY SAFETY AREA BYD RY 27 & RY 05 ENDS.
- NUMEROUS OBJECTS AFFECTING NAVIGABLE AIRSPACE AROUND EACH RWY. EXCERCISE CAUTION WHEN USING THIS FACILITY.
- E111 PRVDD E/W RWY IS ABDND UPON ACTVTN OF NEW E/W (09/27) RWY; APCH TO EACH RWY IS MAINTD FOR A MIN 20:1 GS & TRSNL SFC MAINTD FOR A 7:1 SLOPE.
Images and information placed above are from
http://www.airport-data.com/airport/3GV/
We thank them for the data!
| General Info
|
|---|
| Country |
United States
|
| State |
MISSOURI
|
| FAA ID |
3GV
|
| Latitude |
39-00-56.024N
|
| Longitude |
094-12-47.809W
|
| Elevation |
835 feet
|
| Near City |
GRAIN VALLEY
|
We don't guarantee the information is fresh and accurate. The data may
be wrong or outdated.
For more up-to-date information please refer to other sources.
|
|
