Location & QuickFacts
| FAA Information Effective: | 2008-09-25 |
| Airport Identifier: | 0N0 |
| Airport Status: | Operational |
| Longitude/Latitude: | 094-26-32.8000W/39-17-23.4000N
-94.442444/39.289833 (Estimated) |
| Elevation: | 1004 ft / 306.02 m (Surveyed) |
| Land: | 67 acres |
| From nearest city: | 3 nautical miles NW of Liberty, MO |
| Location: | Clay County, MO |
| Magnetic Variation: | 05E (1985) |
Owner & Manager
| Ownership: | Privately owned |
| Owner: | Aire Kare Inc |
| Address: | 11001 Ne 112th St.
Kansas City, MO 64157 |
| Phone number: | 816-781-4326 |
| Manager: | Paul Stuber |
| Address: | 11001 Ne 112th St.
Kansas City, MO 64057 |
| Phone number: | 816-781-7194 |
Airport Operations and Facilities
| Airport Use: | Open to public |
| Wind indicator: | Yes |
| Segmented Circle: | No |
| Control Tower: | No |
| Lighting Schedule: | RDO-CTL
ACTVT MIRL RY 18/36 - CTAF. |
| Landing fee charge: | No |
| Sectional chart: | Kansas City |
| Region: | ACE - Central |
| Boundary ARTCC: | ZKC - Kansas City |
| Tie-in FSS: | COU - Columbia |
| FSS on Airport: | No |
| FSS Toll Free: | 1-800-WX-BRIEF |
| NOTAMs Facility: | COU (NOTAM-d service avaliable) |
Airport Communications
| CTAF: | 122.800 |
| Unicom: | 122.800 |
Airport Services
| Fuel available: | 100LLMOGAS |
| Bottled Oxygen: | NONE |
| Bulk Oxygen: | NONE |
Runway Information
Runway 18/36
| Dimension: | 2780 x 20 ft / 847.3 x 6.1 m |
| Surface: | ASPH, Good Condition |
| Edge Lights: | Non-standard lighting system
NSTD MIRL; LGTS 40-50 FT LEFT & RIGHT OF CNTRLN AT 100 FT DSTCS ON WEST SIDE; VARIOUS DSTCS ON EAST SIDE; 2 RED THLD LGTS AT EACH THLD. |
| |
Runway 18 |
Runway 36 |
| Longitude: | 094-26-30.8000W | 094-26-34.8300W |
| Latitude: | 39-17-37.0400N | 39-17-09.7400N |
| Traffic Pattern: | Left | Left |
| Markings: | Nonstandard, Good Condition
RWY 18 NSTD NPI MARKINGS; SMALL NR DESIGNATIONS, THLD MARKINGS, & DASHED CNTRLN. | Nonstandard, Good Condition
RWY 36 NSTD BASIC MARKINGS; SMALL NR DESIGNATIONS & DASHED CNTRLN. |
| Obstruction: | 54 ft trees, 460.0 ft from runway, 100 ft right of centerline, 4:1 slope to clear
RWY 18 1-20 FT GND; BLDGS & AUTO PARKING AREA 0-200 FT FM RY END, 10-125 FT R. | 24 ft trees, 482.0 ft from runway, 130 ft left of centerline, 11:1 slope to clear
RWY 36 +1-4 FT GND & FC 25-30 FT FROM RY END L & R. |
|
Radio Navigation Aids
| ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
| GPH | NDB | Mosby | | 284.00 | 03E | 7.1 nm |
| DO | NDB | Dotte | | 359.00 | 05E | 14.9 nm |
| GQ | NDB | Norge | | 517.00 | 05E | 17.0 nm |
| GKB | NDB | Norge | | 517.00 | 05E | 17.0 nm |
| LXT | NDB | Lesumit | | 263.00 | 04E | 20.1 nm |
| EZZ | NDB | Cameron | | 394.00 | 03E | 27.6 nm |
| AZN | NDB | Amazon | | 233.00 | 06E | 41.7 nm |
| RIS | VOR/DME | Riverside | 051X | 111.40 | 05E | 12.5 nm |
| OJC | VOR/DME | Johnson County | 077X | 113.00 | 06E | 30.3 nm |
| BQS | VOR/DME | Braymer | 049X | 111.20 | 03E | 33.3 nm |
| MCI | VORTAC | Kansas City | 079Y | 113.25 | 05E | 13.7 nm |
| ANX | VORTAC | Napoleon | 087X | 114.00 | 07E | 18.7 nm |
| STJ | VORTAC | St Joseph | 102X | 115.50 | 08E | 46.1 nm |
| MKC | VOT | Kansas City Downtown | | 108.60 | | 12.4 nm |
Remarks
- WILDLIFE ON & INVOF RY ESPECIALLY EARLY MORNING HRS.
- NSTD RY SAFETY AREAS BEYOND BOTH RY ENDS; RY 18 END LARGE DROP OFF; RY 36 HAS 4 FT FENCE 15 FT FM RY END.
- PRVDD THE APCH TO EACH RWY IS MAINTD FOR A MIN 20:1 GLIDE SLOPE & THE TRANSITIONAL SFC BE MAINTD FOR A 7:1.
Images and information placed above are from
http://www.airport-data.com/airport/0N0/
We thank them for the data!
| General Info
|
|---|
| Country |
United States
|
| State |
MISSOURI
|
| FAA ID |
0N0
|
| Latitude |
39-17-28.007N
|
| Longitude |
094-26-31.824W
|
| Elevation |
1004 feet
|
| Near City |
LIBERTY
|
We don't guarantee the information is fresh and accurate. The data may
be wrong or outdated.
For more up-to-date information please refer to other sources.
|
|
