Diving Rock Seaplane Base Airport |
 |
(Click on the photo to enlarge) |
 |
(Click on the photo to enlarge) |
Location & QuickFacts
| FAA Information Effective: | 2008-09-25 |
| Airport Identifier: | 07NH |
| Airport Status: | Operational |
| Longitude/Latitude: | 072-03-50.0000W/43-10-32.0000N
-72.063889/43.175556 (Estimated) |
| Elevation: | 1404 ft / 427.94 m (Estimated) |
| Land: | 0 acres |
| From nearest city: | 2 nautical miles E of Washington, NH |
| Location: | Sullivan County, NH |
| Magnetic Variation: | () |
Owner & Manager
| Ownership: | Privately owned |
| Owner: | Craig Gebo |
| Address: | P.o. Box 478
Berlin, MA 01503 |
| Phone number: | 978-838-2230 |
| Manager: | Craig Gebo |
| Address: | P.o. Box 478
Berlin, MA 01503 |
| Phone number: | 603-495-2028 |
Airport Operations and Facilities
| Airport Use: | Private |
| Segmented Circle: | No |
| Control Tower: | No |
| Region: | ANE - New England |
| Boundary ARTCC: | ZBW - Boston |
| Tie-in FSS: | BGR - Bangor |
| FSS Toll Free: | 1-800-WX-BRIEF |
Runway Information
Runway 05W/23W
| Dimension: | 2500 x 200 ft / 762.0 x 61.0 m |
| Surface: | WATER, |
| |
Runway 05W |
Runway 23W |
| Traffic Pattern: | Left | Left |
| Obstruction: | 40 ft pline, 230.0 ft from runway | |
|
Runway 17W/35W
| Dimension: | 2500 x 200 ft / 762.0 x 61.0 m |
| Surface: | WATER, |
| |
Runway 17W |
Runway 35W |
| Traffic Pattern: | Left | Left |
|
Radio Navigation Aids
| ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
| LCI | FAN MARKER | Laconia | | | | 36.0 nm |
| R | FAN MARKER | Chitt | | | 14W | 48.5 nm |
| CNH | NDB | Claremont | | 233.00 | 16W | 17.8 nm |
| SXD | NDB | Springfield | | 265.00 | 15W | 23.6 nm |
| CO | NDB | Epsom | | 216.00 | 16W | 27.0 nm |
| IVV | NDB | White River | | 379.00 | 16W | 29.0 nm |
| AS | NDB | Chern | | 359.00 | 16W | 29.3 nm |
| LC | NDB | Blnap | | 328.00 | 16W | 31.6 nm |
| LAH | NDB | Hanover | | 276.00 | 15W | 32.0 nm |
| DRY | NDB | Derry | | 338.00 | 16W | 34.6 nm |
| ORE | NDB | Orange | | 205.00 | 15W | 37.8 nm |
| VWD | NDB | Mount Snow | | 224.00 | 15W | 38.2 nm |
| FIT | NDB | Fitchburg | | 365.00 | 15W | 39.9 nm |
| LEB | VOR/DME | Lebanon | 084X | 113.70 | 15W | 31.0 nm |
| MHT | VOR/DME | Manchester | 091X | 114.40 | 15W | 35.7 nm |
| RUT | VOR/DME | Rutland | 47X | 111.00 | 15W | 44.1 nm |
| CON | VORTAC | Concord | 076X | 112.90 | 15W | 21.6 nm |
| EEN | VORTAC | Keene | 031X | 109.40 | 14W | 25.0 nm |
| GDM | VORTAC | Gardner | 043X | 110.60 | 14W | 37.8 nm |
Remarks
- 1,000 FT MOUNTAIN 1.8 NM NNE OF SPB.
- PRVDD YOU COMPLY WITH MILITARY CONDITIONS, VFR OPNS, PRIVATE USE & ALL USERS COMPLY WITH THESE CONDITIONS.
Images and information placed above are from
http://www.airport-data.com/airport/07NH/
We thank them for the data!
|
|
