Jaffrey Airport-silver Ranch Airport

Jaffrey Airport - Silver Ranch Airpark
IATA: AFN – ICAO: KAFN – FAA LID: AFN
Summary
Airport type		Public
Owner		Jaffrey Municipal Airport Development Corp.
Serves		Jaffrey, New Hampshire
Elevation AMSL		1,040 ft / 317 m
Coordinates		42°48′18.483″N 072°00′10.879″W / 42.80513417°N 72.00302194°W / 42.80513417; -72.00302194
Website		http://www.silverranchairpark.com/
Runways
Direction	Length		Surface
Direction	ft	m	Surface
16/34	2,982	909	asphalt / turf
Statistics (2008)
Aircraft operations			7,003
Based aircraft			26
Source: Federal Aviation Administration

Jaffrey Airport - Silver Ranch Airpark is a public use airport in Cheshire County, New Hampshire, United States. It is owned by the Jaffrey Municipal Airport Development Corp. and is located one nautical mile (1.85 km) southeast of the central business district of Jaffrey, New Hampshire.

Facilities and aircraft

Jaffrey Airport - Silver Ranch Airpark covers an area of 80 acres (32.4 ha) at an elevation of 1,040 feet (317 m) above mean sea level. It has one asphalt / turf runway designated 16/34 with a surface measuring 2,982 by 134 feet (909 x 41 m).

For the 12-month period ending October 31, 2008, the airport had 7,003 aircraft operations, an average of 19 per day: 86% general aviation, 13% air taxi, 1% military and a few ultralights. At that time there were 26 aircraft based at this airport: 77% single-engine, 4% multi-engine, 8% helicopter and 11% ultralights.

The above content comes from Wikipedia and is published under free licenses – click here to read more.

Jaffrey Airport-silver Ranch Airport picture

Location & QuickFacts

FAA Information Effective:	2008-09-25
Airport Identifier:	AFN
Airport Status:	Operational
Longitude/Latitude:	072-00-10.8790W/42-48-18.4830N -72.003022/42.805134 (Estimated)
Elevation:	1040 ft / 316.99 m (Surveyed)
Land:	80 acres
From nearest city:	1 nautical miles SE of Jaffrey, NH
Location:	Cheshire County, NH
Magnetic Variation:	15W (1985)

Owner & Manager

Ownership:	Privately owned
Owner:	Jaffrey Muni Arpt Dev. Corp
Address:	190 Turnpike Rd, Jaffrey Airport Jaffrey, NH 03452
Manager:	Harvey N Sawyer
Address:	Jaffrey Arpt Silver Ranch Airpark, 190 Turnpike Rd Jaffrey, NH 03452
Phone number:	603-532-8870

Airport Operations and Facilities

Airport Use:	Open to public
Wind indicator:	Yes
Segmented Circle:	No
Control Tower:	No
Lighting Schedule:	DUSK-DAWN PPR FOR NSTD LIRL RY 16/34 - CALL 603-532-8870.
Beacon Color:	Clear-Green (lighted land airport) ROTG BCN OTS INDEFLY.
Landing fee charge:	No
Sectional chart:	New York
Region:	ANE - New England
Traffic Pattern Alt:	1000 ft
Boundary ARTCC:	ZBW - Boston
Tie-in FSS:	BGR - Bangor
FSS on Airport:	No
FSS Toll Free:	1-800-WX-BRIEF
NOTAMs Facility:	AFN (NOTAM-d service avaliable)
Federal Agreements:	N

Airport Communications

CTAF:	122.800
Unicom:	122.800

Airport Services

Fuel available:	100LL
Airframe Repair:	MINOR
Power Plant Repair:	MINOR
Bottled Oxygen:	NONE
Bulk Oxygen:	NONE

Runway Information

Runway 16/34

Dimension:

2982 x 134 ft / 908.9 x 40.8 m

Surface:

ASPH-TURF, Fair Condition
CENTER 50 FT WIDE PORTION OF THE ENTIRE RY LENGTH IS ASPHALT; THE REMAINING 84 FT PORTION OF THE RY WIDTH IS MADE UP OF TWO 42 FT WIDE STRIPS OF TURF; ONE ON EACH SIDE OF THE ASPHALT ENTIRE LENGTH OF RY.

Weight Limit:

Single wheel: 8000 lbs.

Edge Lights:

Non-standard lighting system
RY 16/34 NSTD LIRL; FIRST 582 FT RY 34 NOT LIGHTED; THLD LIGHTS AT 582 FT.

	Runway 16	Runway 34
Longitude:	072-00-21.4670W	072-00-00.2950W
Latitude:	42-48-30.9800N	42-48-05.9920N
Elevation:	1040.00 ft	1013.00 ft
Alignment:	127	127
Traffic Pattern:	Left	Left
Markings:	Basic, Good Condition MARKINGS FADED, NOT VIS.	Basic, Good Condition MARKINGS FADED, NOT VIS.
Displaced threshold:	0.00 ft	582.00 ft
Runway End Identifier:	No
Centerline Lights:	No	No
Touchdown Lights:	No	No
Obstruction:	18 ft tree, 262.0 ft from runway, 95 ft left of centerline, 4:1 slope to clear	30 ft grnd, 200.0 ft from runway RWY 34 APCH SLOPE 28:1 TO DSPLCD THR +6 FT GND 50 FT FM THR RISING TO +30 FT GND 200 FT FM THR.

Radio Navigation Aids

ID	Type	Name	Ch	Freq	Var	Dist
BVY	FAN MARKER	Beverly				48.2 nm
AS	NDB	Chern		359.00	16W	17.7 nm
FIT	NDB	Fitchburg		365.00	15W	18.7 nm
ORE	NDB	Orange		205.00	15W	18.9 nm
DRY	NDB	Derry		338.00	16W	27.0 nm
CO	NDB	Epsom		216.00	16W	30.7 nm
CNH	NDB	Claremont		233.00	16W	37.6 nm
SXD	NDB	Springfield		265.00	15W	37.9 nm
VWD	NDB	Mount Snow		224.00	15W	38.6 nm
SKR	NDB	Shaker Hill		251.00	16W	42.1 nm
TOF	NDB	Topsfield		269.00	16W	47.5 nm
LC	NDB	Blnap		328.00	16W	48.5 nm
IVV	NDB	White River		379.00	16W	49.7 nm
MHT	VOR/DME	Manchester	091X	114.40	15W	28.2 nm
LWM	VOR/DME	Lawrence	072X	112.50	15W	40.3 nm
EEN	VORTAC	Keene	031X	109.40	14W	12.8 nm
GDM	VORTAC	Gardner	043X	110.60	14W	15.8 nm
CON	VORTAC	Concord	076X	112.90	15W	31.2 nm
CEF	VORTAC	Westover	87X	114.00	14W	43.3 nm
BAF	VORTAC	Barnes	077X	113.00	14W	49.9 nm
ORH	VOT	Worcester		108.20		32.9 nm
BED	VOT	Laurence G Hanscom Fld		110.00		37.5 nm

Remarks

ULTRALIGHT ACTIVITY ON ARPT.
PARALLEL TWY SERVES HANGAR/RAMP ONLY - NO ACCESS TO RY 34.
PAEW AER RY 34; MAXIMUM EQUIPMENT HEIGHT 50 FT AGL; AER RY 34 OBSTRUCTION LGTS OTS.
WILDLIFE ON & INVOF ARPT.
ESTAB PRIOR 1959

Images and information placed above are from
http://www.airport-data.com/airport/AFN/

We thank them for the data!

General Info
Country United States
State NEW HAMPSHIRE
FAA ID AFN
Latitude 42-48-18.483N
Longitude 072-00-10.879W
Elevation 1040 feet
Near City JAFFREY
