| Parlin Field |
| IATA: NWH – ICAO: none – FAA LID: 2B3 |
| Summary |
| Airport type |
Public |
| Owner |
Town of Newport |
| Serves |
Newport, New Hampshire |
| Elevation AMSL |
784 ft / 239 m |
| Coordinates |
43°23′17.266″N 072°11′21.315″W / 43.38812944°N 72.18925417°W / 43.38812944; -72.18925417 |
| Website |
http://www.newportnh.net/index.php?nav=147 |
| Runways |
| Direction |
Length |
Surface |
| ft |
m |
| 12/30 |
1,950 |
594 |
turf |
| 18/36 |
3,450 |
1,052 |
asphalt |
| Statistics (2008) |
| Aircraft operations |
2,901 |
| Based aircraft |
23 |
| Source: Federal Aviation Administration |
Parlin Field is a public use airport in Sullivan County, New Hampshire, United States. It is owned by the Town of Newport and is located two nautical miles (3.74 km) south of the central business district.
Although most U.S. airports use the same three-letter location identifier for the FAA and IATA, this airport is assigned 2B3 by the FAA, but has the designation NWH from the IATA.
Facilities and aircraft
Parlin Field covers an area of 125 acres (50.6 ha) at an elevation of 784 feet (239 m) above mean sea level. It has two runways designated 12/30, with a turf surface measuring 1,950 by 80 feet (594 x 24 m) and 18/36, with an asphalt surface measuring 3,450 by 50 feet (1,052 x 15 m).
For the 12-month period ending August 31, 2008, the airport had 2,901 aircraft operations, an average of 8 per day: 100% general aviation with a few ultralights. At that time there were 23 aircraft based at this airport: 91% single-engine, 4% multi-engine and 4% ultralights.
The above content comes from Wikipedia and is published under free licenses – click here to read more.
Location & QuickFacts
| FAA Information Effective: | 2008-09-25 |
| Airport Identifier: | 2B3 |
| Airport Status: | Operational |
| Longitude/Latitude: | 072-11-21.3150W/43-23-17.2660N
-72.189254/43.388129 (Estimated) |
| Elevation: | 784 ft / 238.96 m (Surveyed) |
| Land: | 125 acres |
| From nearest city: | 2 nautical miles NW of Newport, NH |
| Location: | Sullivan County, NH |
| Magnetic Variation: | 16W (1985) |
Owner & Manager
| Ownership: | Publicly owned |
| Owner: | Town Of Newport |
| Address: | 15 Sunapee St.
Newport, NH 03773 |
| Phone number: | 603-863-1877 |
| Manager: | Dean Stetson |
| Address: | 14 Airport Road
Newport, NH 03773 |
| Phone number: | 603-863-5192 |
Airport Operations and Facilities
| Airport Use: | Open to public |
| Wind indicator: | Yes |
| Segmented Circle: | No |
| Control Tower: | No |
| Lighting Schedule: | DUSK-DAWN |
| Landing fee charge: | No |
| Sectional chart: | New York |
| Region: | ANE - New England |
| Boundary ARTCC: | ZBW - Boston |
| Tie-in FSS: | BGR - Bangor |
| FSS on Airport: | No |
| FSS Toll Free: | 1-800-WX-BRIEF |
| NOTAMs Facility: | BGR (NOTAM-d service avaliable) |
| Federal Agreements: | N1 |
Airport Communications
| CTAF: | 122.800 |
| Unicom: | 122.800 |
Airport Services
| Fuel available: | 100LL
SELF SERVICE FUEL AVBL 24 HRS WITH CREDIT CARD. |
| Airframe Repair: | NONE |
| Power Plant Repair: | NONE |
| Bottled Oxygen: | NONE |
| Bulk Oxygen: | NONE |
Runway Information
Runway 12/30
| Dimension: | 1950 x 80 ft / 594.4 x 24.4 m |
| Surface: | TURF, Good Condition
+2 INCH CRACKS THROUGHOUT RUNWAY SURFACE |
| |
Runway 12 |
Runway 30 |
| Traffic Pattern: | Right | Left |
| Obstruction: | 70 ft trees, 50.0 ft from runway | 80 ft tree, 952.0 ft from runway, 100 ft left of centerline, 12:1 slope to clear |
|
Runway 18/36
| Dimension: | 3450 x 50 ft / 1051.6 x 15.2 m |
| Surface: | ASPH, Fair Condition
+2 INCH CRACKS THROUGHOUT RUNWAY SURFACE |
| Weight Limit: | Single wheel: 12000 lbs. |
| Edge Lights: | Non-standard lighting system
NSTD RY LGTS. RY 18 END INDICATORS NSTD REFLECTOR BARS. |
| |
Runway 18 |
Runway 36 |
| Traffic Pattern: | Right | Left |
| Markings: | Basic, Poor Condition
MARKINGS FADED. | Basic, Poor Condition
MARKINGS FADED |
| Displaced threshold: | 690.00 ft | 240.00 ft |
| Obstruction: | 77 ft trees, 213.0 ft from runway, 16 ft left of centerline
APCH RATIO 11:1 TO DSPLCD THR.
RWY 18, +15 FT ROAD 20 FT FM RWY END, +4 FT BERM AT RWY END. | 35 ft trees, 210.0 ft from runway, 112 ft right of centerline
RWY 36 APCH RATIO 17:1 TO DSPLCD THLD.
RWY 36, +30 FT TREE 153 FEET FROM RWY END, 103 FT RIGHT |
|
Radio Navigation Aids
| ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
| LCI | FAN MARKER | Laconia | | | | 34.4 nm |
| R | FAN MARKER | Chitt | | | 14W | 37.3 nm |
| CNH | NDB | Claremont | | 233.00 | 16W | 8.0 nm |
| IVV | NDB | White River | | 379.00 | 16W | 15.9 nm |
| SXD | NDB | Springfield | | 265.00 | 15W | 18.8 nm |
| LAH | NDB | Hanover | | 276.00 | 15W | 18.9 nm |
| LC | NDB | Blnap | | 328.00 | 16W | 29.8 nm |
| CO | NDB | Epsom | | 216.00 | 16W | 36.1 nm |
| DYO | NDB | Smuto | | 221.00 | 15W | 38.5 nm |
| VWD | NDB | Mount Snow | | 224.00 | 15W | 40.5 nm |
| AS | NDB | Chern | | 359.00 | 16W | 42.6 nm |
| DRY | NDB | Derry | | 338.00 | 16W | 46.7 nm |
| ORE | NDB | Orange | | 205.00 | 15W | 49.4 nm |
| LEB | VOR/DME | Lebanon | 084X | 113.70 | 15W | 17.5 nm |
| RUT | VOR/DME | Rutland | 47X | 111.00 | 15W | 34.2 nm |
| MPV | VOR/DME | Montpelier | 045X | 110.80 | 16W | 43.4 nm |
| MHT | VOR/DME | Manchester | 091X | 114.40 | 15W | 47.6 nm |
| CON | VORTAC | Concord | 076X | 112.90 | 15W | 28.7 nm |
| EEN | VORTAC | Keene | 031X | 109.40 | 14W | 36.0 nm |
Remarks
- RY 12/30 CLSD NOV TO MAY.
- RY 18 MTN 981' MSL 2500' FM THR 600'R.
- WILDLIFE ON & INVOF ARPT.
- ESTAB PRIOR TO 1959.
Images and information placed above are from
http://www.airport-data.com/airport/2B3/
We thank them for the data!
| General Info
|
| Country |
United States
|
| State |
NEW HAMPSHIRE
|
| FAA ID |
2B3
|
| Latitude |
43-23-17.266N
|
| Longitude |
072-11-21.315W
|
| Elevation |
784 feet
|
| Near City |
NEWPORT
|
We don't guarantee the information is fresh and accurate. The data may
be wrong or outdated.
For more up-to-date information please refer to other sources.
|
|
