Location & QuickFacts
FAA Information Effective: | 2008-09-25 |
Airport Identifier: | OR09 |
Airport Status: | Operational |
Longitude/Latitude: | 118-15-27.0850W/42-20-08.3010N -118.257524/42.335639 (Estimated) |
Elevation: | 4447 ft / 1355.45 m (Estimated) |
Land: | 0 acres |
From nearest city: | 18 nautical miles NE of Fields, OR |
Location: | Harney County, OR |
Magnetic Variation: | 17E (1985) |
Owner & Manager
Ownership: | Privately owned |
Owner: | R E Naftzger |
Address: | 9601 Wilshire Blvd, Suite 500 Beverly Hills, CA 90210 |
Phone number: | 213-272-0955 |
Manager: | A B Cherry Fld Supv |
Address: | 9601 Wilshire Blvd, Suite 500 Beverly Hills, CA 90210 |
Phone number: | 503-495-2222 OR 213-878-3838. |
Airport Operations and Facilities
Airport Use: | Private |
Wind indicator: | Yes |
Segmented Circle: | No |
Control Tower: | No |
Lighting Schedule: | DUSK-DAWN |
Beacon Color: | Clear-Green (lighted land airport) |
Landing fee charge: | No |
Sectional chart: | Klamath Falls |
Region: | ANM - Northwest Mountain |
Boundary ARTCC: | ZLC - Salt Lake City |
Tie-in FSS: | MMV - Mc Minnville |
FSS on Airport: | No |
FSS Toll Free: | 1-800-WX-BRIEF |
Airport Services
Fuel available: | 100 |
Airframe Repair: | NONE |
Power Plant Repair: | NONE |
Runway Information
Runway 03/21
Dimension: | 3025 x 94 ft / 922.0 x 28.7 m |
Surface: | DIRT, |
Edge Lights: | Low |
|
Runway 03 |
Runway 21 |
Traffic Pattern: | Left | Left |
|
Runway 12/30
Dimension: | 3247 x 94 ft / 989.7 x 28.7 m |
Surface: | DIRT, |
Edge Lights: | Low |
|
Runway 12 |
Runway 30 |
Traffic Pattern: | Left | Left |
|
Radio Navigation Aids
ID |
Type |
Name |
Ch |
Freq |
Var |
Dist |
RMD | NDB | Mc Dermitt State | | 204.00 | 17E | 30.8 nm |
REO | VORTAC | Rome | 072X | 112.50 | 19E | 23.1 nm |
Remarks
- APT LCTD 21 NM 210 DEG FM ROME, OR VOR, APT IS 1 MI W OF LARGE GROUP OF RANCH BLDGS.
- ESTABD PRIOR TO MAY 1959.
Images and information placed above are from
http://www.airport-data.com/airport/OR09/
We thank them for the data!
General Info
|
Country |
United States
|
State |
OREGON
|
FAA ID |
OR09
|
Latitude |
42-20-08.301N
|
Longitude |
118-15-27.085W
|
Elevation |
4447 feet
|
Near City |
FIELDS
|
We don't guarantee the information is fresh and accurate. The data may
be wrong or outdated.
For more up-to-date information please refer to other sources.
|
|
